Omal Velox 1300

$43,940.00

Omal Velox 1300

$43,940.00

CNC controlled drill & dowel inserter

The OMAL Velox 1300 is a Horizontal Bore, Glue and Dowel and numerically controlled machines to drill, glue and insert dowels on horizontal pieces. The OMAL system of bore and dowel yields a cycle time of approximately ONE second for each bore, glue and dowel insertion when holes are on 32mm intervals.

Technical Data

Technical data

Panel length 20 mm (3/4”) – 1300 mm
Panel width 40 mm  (1.57”) – ∞
Panel thickness 10 mm (3/8”) – 25.4 mm (1”)
Installed power 10 Kw
Compressed air 6 BAR
Dust extraction hood 60 mm (2 3/8”)
Dust extraction 250 cfm
Width “X” CNC 1300 mm (51”)
Depth “Y” manual 40 mm (1.57”)
Vertical “Z” manual 40 mm (1.57”)
Voltage 220V/60Hz/3~
Net weight ~1000 kg (2200 lbs)
